HS-85MG Micro Analog Metal Gear Servo

Item No. HRC32085S
HS-85MG Micro Analog Metal Gear Servo
HS-85MG Micro Analog Metal Gear Servo
HS-85MG Micro Analog Metal Gear Servo
HS-85MG Micro Analog Metal Gear Servo
Brand Logo
4.3 out of 5 Customer Rating

HS-85MG Micro Analog Metal Gear Servo

Item No. HRC32085S
$33.99
In Stock
Selected Store
The link to HS-85MG Micro Analog Metal Gear Servo has been copied

Product Details

The HS-85MG features a high power motor for greater speed and torque. The HS-85MG is the choice of modelers looking for a high performance servo without breaking the bank. The ball bearing supported output shaft and sturdy gear trains are preferred for smaller glow and electric airplanes, heli’s and sail planes.
Key Features
  • Speed: @4.8V .16sec/60' / @6.0V .14sec/60'
  • Torque: @4.8V 41.66oz/in / @6.0V 48.60oz/in
  • High Torque and Precision Centering
  • Rugged Metal Gears
  • Ball Bearing-Supported Output Shaft
  • Perfect for Applications where a Standard Servo is too Heavy or Large but Standard Torque is Required
In The Box
  • (1) HS-85MG Micro Analog Metal Gear Servo
HS-85MG Micro Analog Metal Gear Servo
Quick Links
Manuals & Support

Product Specs

Maximum Servo Torque
42oz/in @ 4.8V, 49oz/in @ 6.0V
Current Draw Stall
1,200 mA
Motor Type
Brushed
Servo Operating Voltage
4.8 - 6.0V
Current Draw Idle
8mA
Product Width
0.51" (13 mm)
Connector Type
Universal
Maximum Servo Speed
0.16 sec/60 deg @ 4.8V, 0.14 sec/60 deg @ 6.0V
Product Length
1.14" (29 mm)
Programmable
No
Servo Size Category
Micro
Application
Small Glow, Electric Aircraft, Helicopters, Cars, Boats
Product Weight
0.77oz (21.9g)
Spline Count
24 - Tooth
Water-Resistant
No
Bearing
Top Ball Bearing
Bushing Or Bearing
Bearing
Gear Type
Metal
Wire Gauge
28 AWG
Deadband
>5µs
Input Voltage
4.8V ~ 6.0V
Product Height
1.18" (30 mm)
Servo Type
Analog
