HS-5565MH Standard Digital HV High Speed Metal Gear Servo

Item No. HRC35565S
HS-5565MH Standard Digital HV High Speed Metal Gear Servo
HS-5565MH Standard Digital HV High Speed Metal Gear Servo
HS-5565MH Standard Digital HV High Speed Metal Gear Servo
HS-5565MH Standard Digital HV High Speed Metal Gear Servo
HS-5565MH Standard Digital HV High Speed Metal Gear Servo
Backorder
Brand Logo
4.9 out of 5 Customer Rating

HS-5565MH Standard Digital HV High Speed Metal Gear Servo

Item No. HRC35565S
$72.99
Earn points on this item ⓘ
Next Shipment March 2023
Selected Store
The link to HS-5565MH Standard Digital HV High Speed Metal Gear Servo has been copied

Product Details

Increase your performance not your budget with the high voltage, high speed, digital HS-5565MH. Featuring a high performance coreless motor, heavy-duty metal gears and dual ball bearings, the HS-5565MH is rated for 7.4 volt, 2S LiPo operation The HS-5565MH brings lightning speed and acceleration to your 1/10th scale touring cars, buggies and short course vehicles, helicopters up to .90-size and sport to high performance aircraft up to 25 percent.
Key Features
  • Speed: @4.8V .11sec/60' / @6.0V .09sec/60'
  • Torque: @4.8V 153oz/in / @6.0V 194oz/in
  • Quick and Precise Coreless Motor
  • Heavy Duty Metal Gears
  • 7.4v 2-Cell LiPo Capability
  • Standard Programmable Digital Circuit
In The Box
  • (1) HS-5565MH Standard Digital HV High Speed Metal Gear Servo
HS-5565MH Standard Digital HV High Speed Metal Gear Servo
Quick Links
Manuals & Support

Overview

Increase your performance not your budget with the high voltage, digital HS-5565MH. This premium sport servo features a coreless motor, heavy-duty metal gears and dual ball bearings. Rated at 7.4 volts for 2S LiPo operation, it provides the durability and power your RC hobby demands. The HS-5565MH brings lightning speed and acceleration to your 1/10th scale touring cars, buggies and short course vehicles, helicopters up to .90-size and sport to high performance aircraft up to 25 percent.

Product Specifications

Current Draw Stall 2,700 mA
Motor Type Brushed
Servo Operating Voltage 6.0 - 7.4V (HV)
Bearing Dual Ball Bearing
Bushing Or Bearing Bearing
Gear Type Metal
Wire Gauge 25 AWG
Maximum Servo Torque 153oz/in @ 6.0V, 194oz/in @ 7.4V
Current Draw Idle 4 mA
Product Width 0.78" (20 mm)
Connector Type Universal
Maximum Servo Speed 0.11 sec.60 deg @ 6.0V, 0.09 sec/60 deg @ 7.4V
Product Length 1.57" (40 mm)
Application Sport Aircraft, Helicopters, Cars, Boats
Product Weight 2.10oz (60.0g)
Spline Count 24 - Tooth
Water-Resistant No
Deadband 2µs
Input Voltage 6.0V ~ 7.4V
Product Height 1.49" (38 mm)
Servo Type Digital
Programmable Yes
Servo Size Category Standard
