HS-5496MH Standard Digital HV Metal Gear Servo

Item No. HRC35496S
Brand Logo
4.2 out of 5 Customer Rating

HS-5496MH Standard Digital HV Metal Gear Servo

Item No. HRC35496S
$39.99
Earn points on this item
In Stock
Selected Store

Product Details

Key Features
  • Designed to be powered from a 2-cell 7.4V LiPo battery for extra speed and power
  • Ideal for 1/10 to 1/8 scale on- and off-road vehicles, larger sport helis and large scale aerobatic aircraft up to 25%
  • Programmable features include; Dead Band Width, Rotation Direction, Rotation Speed, End Points/Neutral Points, Fail Safe On/Off, Fail Safe Point
  • Heavy duty metal gear train (MK first gear)
In The Box
  • HS-5696MH High Torque
  • High Volt Metal Gear Servo with Connector
  • 0.94" (24mm) round horn
  • 1.8" (45mm) round horn
  • 1.7" (44mm) 4-point round horn
  • 0.98" (25mm) single arm horn
  • 2.3" (59mm) double arm horn
  • 0.87" (22mm) mounting hardware
  • Instruction Sheet
Needed to Complete
  • Installing in model and connecting linkage

Programmable Functions

  • End Point Adjustments
  • Direction
  • Fail Safe
  • Dead Band
  • Speed (Slower)
  • Data Save / Load
  • Program Reset

Overview

At Hitec, we believe in developing the highest quality servos in the market at an affordable price. That philosophy stands true with the economical HS-5496MH metal gear digital sport servo. Based on the popular HS-5485HB, the HS-5496MH is the perfect match for match for sport airplanes up to 25% scale as well as sport cars and trucks. With 7.4 volt, 2-cell LiPo battery capability, The HS-5496MH delivers the power you need at a price you can feel good about! Trust your hobby to Hitec.

Product Specifications

Product Length 1.57 in (39.8mm)
Programmable Yes
Servo Size Category Standard
Current Draw Stall 1,400mA
Servo Operating Voltage 6.0 - 7.4V (HV)
Current Draw Idle 12mA
Product Width 0.78 in (19.8oz)
Gear Type Metal
Maximum Servo Speed 0.17 sec/60 deg @ 6.0V; 0.15 sec/60 deg @ 7.4V
Bearing Single
Bushing Or Bearing Bearing
Product Height 1.49 in (38.0mm)
Servo Type Digital
Product Weight 1.84 oz (52.0g)
Spline Count 24 Teeth
Max Servo Torque 100-199 oz-in
Application 50-64oz sport & scale planes, 2M & up sailplanes, 1M sailboat, 1:10 scale power boat
