HS-5087MH Micro Digital HV Metal Gear Servo

Item No. HRC35087S
HS-5087MH Micro Digital HV Metal Gear Servo
HS-5087MH Micro Digital HV Metal Gear Servo
HS-5087MH Micro Digital HV Metal Gear Servo
HS-5087MH Micro Digital HV Metal Gear Servo
Brand Logo
3.8 out of 5 Customer Rating

HS-5087MH Micro Digital HV Metal Gear Servo

Item No. HRC35087S
$42.99
In Stock
Selected Store
The link to HS-5087MH Micro Digital HV Metal Gear Servo has been copied

Product Details

The HS-5087MH digital, metal gear micro servo is the high voltage version of our ever popular HS-5085MG. Built with a 3-pole ferrite motor and heavy-duty metal gears, this servo will bring maximum performance to your hobby and deliver extra power with a 2-cell 7.4V LiPo battery. Whether you are a beginner or an expert in the RC field, our HS-5087MH will provide the strength and capability you need and want in a micro servo. Drivers will find it the perfect steering servo for their 1/16th scale vehicles. Pilots with .15 to .40-size glow and electric aircraft will relish in its power and reliability. Its precision and performance also make it perfect for 500-size helicopters.
Key Features
  • Speed: @4.8V .17sec/60' / @6.0V .13sec/60'
  • Torque: @4.8V 50oz/in / @6.0V 60oz/in
  • Rugged Metal Gears
  • Ball Bearing-Supported Output Shaft
  • Standard Programmable Digital Circuit for More Holding Power
  • Standard Servo Performance in a Micro Package
In The Box
  • (1) HS-5087MH Micro Digital HV Metal Gear Servo
HS-5087MH Micro Digital HV Metal Gear Servo
Quick Links
Manuals & Support

Product Specs

Maximum Servo Torque
50oz/in @ 6.0V, 60oz/in @ 7.4V
Connector Type
Universal
Maximum Servo Speed
0.17 sec/60 deg @ 6.0V, 0.13 sec/60 deg @ 7.4V
Product Length
1.14" (29 mm)
Bearing
Top Ball Bearing
Bushing Or Bearing
Bearing
Gear Type
Metal
Wire Gauge
28 AWG
Programmable
Yes
Servo Size Category
Micro
Current Draw Stall
1,750 mA
Motor Type
Brushed
Servo Operating Voltage
6.0 - 7.4V (HV)
Current Draw Idle
3 mA
Product Width
0.51" (13 mm)
Application
50oz park flyers, 42-50oz sport planes, 2M/DLG sailplanes, 1:16 scale on-road, buggies & SC trucks, 1:16 scale power boats
Product Weight
0.77oz (21.9g)
Spline Count
24 Teeth
Water-Resistant
No
Deadband
2µs
Input Voltage
6.0V ~ 7.4V
Product Height
1.18" (30 mm)
Servo Type
Digital
