HS-5070MH Micro Digital HV Ultra Torque Metal Gear Feather Servo

Item No. HRC35070
Brand Logo
5 out of 5 Customer Rating

HS-5070MH Micro Digital HV Ultra Torque Metal Gear Feather Servo

Item No. HRC35070
$39.99
In Stock
Selected Store

Product Details

Hitec's new strong and speedy digital HS-5070MH possess the performance qualities necessary for the new class of 42-48 inch performance 3D aircraft and 450-size helicopters. Featuring Hitec’s durable metal gears, cored motors, top ball bearings and Generation 1 circuitry, these new additions to our vast servo family will have all your planes and helis flying with remarkable precision and power. The programmable HS-5070MH delivers an impressive 53 oz.-in. of torque at 7.4 volts.
Key Features
  • Speed: @4.8V .14sec/60' / @6.0V .12sec/60'
  • Torque: @4.8V 42oz/in / @6.0V 53oz/in
  • End Point Adjustments
In The Box
  • (1) HS-5070MH Micro Digital HV Ultra Torque Metal Gear Feather Servo
HS-5070MH Micro Digital HV Ultra Torque Metal Gear Feather Servo

Product Specs

Maximum Servo Torque
42oz/in @ 6.0V, 53oz/in @ 7.4V
Current Draw Stall
1,300 mA
Motor Type
Brushed
Servo Operating Voltage
6.0 - 7.4V (HV)
Bearing
Top Ball Bearing
Bushing Or Bearing
Bearing
Gear Type
Metal
Wire Gauge
28 AWG
Current Draw Idle
3 mA
Product Width
0.45" (11 mm)
Programmable
Yes
Servo Size Category
Micro
Application
65oz or less parkflyers, 36-41oz sport planes, 2M/DLG sailplanes, 500-750mm electric helis, 30-39 class gas helis, 1:16 scale power boats, buggies & on-road vehicles
Number of Poles
3
Product Weight
0.50oz (14.2g)
Water-Resistant
No
Deadband
2µs
Input Voltage
6.0V ~ 7.4V
Product Height
1.14" (29 mm)
Servo Type
Digital
Connector Type
Universal
Maximum Servo Speed
0.14 sec/60 deg @ 6.0V, 0.12 sec/60 deg @ 7.4V
Product Length
0.92" (23 mm)
