HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo

Item No. HRC32070
HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo
HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo
HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo
Brand Logo
5 out of 5 Customer Rating

HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo

Item No. HRC32070
$34.99
In Stock
Selected Store
The link to HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo has been copied

Product Details

Hitec's strong and speedy analog HS-70MG possess the performance qualities necessary for the new class of 42-48 inch performance 3D aircraft and 450-size helicopters. Featuring Hitec’s durable metal gears, cored motors, top ball bearings and Generation 1 circuitry, these new additions to our vast servo family will have all your planes and helis flying with remarkable precision and power.
Key Features
  • Torque: @4.8V 33.33oz/in / @6.0V 41.66oz/in
  • Speed: @4.8V .17sec/60' / @6.0V .14sec/60'
In The Box
  • HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo
HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo
Quick Links
Manuals & Support

Product Specs

Application
36-41oz sport plane, 2M/DLG sailplane, 400-500mm electric heli, 30-39 class gas heli, 1:8 scale SC trucks, 1:8 scale power boats
Bearing
Top Ball Bearing
Bushing Or Bearing
Bearing
Connector Type
Universal
Current Draw Idle
8 mA
Current Draw Stall
1,250mA
Deadband
5µs
Gear Type
Metal
Input Voltage
4.8V ~ 6.0V
Maximum Servo Speed
0.17 sec/60 deg @ 4.8V, 0.14 sec/60 deg @ 6.0V
Maximum Servo Torque
33oz/in @ 4.8V, 42oz/in @ 6.0V
Motor Type
Brushed
Number of Poles
3
Product Height
1.14" (29 mm)
Product Length
0.92" (23 mm)
Product Weight
0.50 oz (14.2g)
Product Width
0.45" (11 mm)
Programmable
No
Servo Operating Voltage
4.8 - 6.0V
Servo Size Category
Micro
Servo Type
Analog
Water-Resistant
No
Wire Gauge
28 AWG
